Slitting Rewinding

Slitting Rewinding
Slitting Rewinding
Product Code : ZFQ-1800
Product Description

We are the prominent Manufacturer, Supplier and Exporter in the market, engaged in offering Slitting Machine to our customers. This machine is extensively used for shearing process that cuts large roll of materials into narrower ones. Designed and manufactured by our team of adroit professionals using premium quality components and a machinery, this machine is strictly tested at our high end production unit.  In addition, this Slitting Machine can be easily purchased from us at market leading price range



PAPER SLITTER AND REWINDER

Model

ZFQ-1200/1600/1800

max. unwinding roll weight, kg

1500 kg

max. unwinding roll width, mm

1200/1600/1800

min. unwinding roll width, mm

500 mm

max. unwinding roll diameter, mm

1300 mm

unwinding inner roll core diameter, mm

76

max. cardboard from unwinding roll thickness, mm

0.8mm

min. cardboard from unwinding roll thickness, mm

0.1 mm

max. cardboard from unwinding roll, g/m2

600 gsm

min. cardboard from unwinding roll, g/m2

100 gsm

unwinding speed, revolutions-1 or m/min (mechanical shaft speed)

 1400 rpm

cutting accuracy by width, mm +/-

1 mm

max. distance between disk knifes, mm

1200 mm

min. distance between disk knifes, mm

40 mm

max. winding roll weight, kg

1500 kg

max. winding roll width, mm

1200 mm

min. winding roll width, mm

40 mm

max. winding roll diameter, mm

1300 mm

winding inner roll core diameter, mm

76 mm inner core diameter

winding small rolls quantity (simultaneously)

25
