Specification
Machine model | 500mm Roll to roll |
Unwind width | 600mm |
Mold effective width | 500mm |
Machine working speed | 0 to 80m/min adjustable |
Unwinding diameter | 0 to 1200mm |
Rewinding diameter | 0 to 300mm |
Unwinding stand weight | 1 Ton |
Unwinding shaft | 3 inflatable air shaft |
Rewinding shaft(steel bar) | 1/1.5/2/3 |
Machine size | 2620*1640*1160mm(LWH) |
Machine weight | 1000KG |
Power supply | 380V 3 Phase 5 wires |
Air Pressure | 6 to 8kg/c square meter |
